Firearm

US12723009 - Propellant charge

The invention is directed to a propellant charge for guns, to a combination of a propellant charge and a primer, to a firearms cartridge, and to a method for modifying the surface of a propellant charge. The propellant charge of the invention comprises multiple propellant grains, wherein an exterior part of part of the propellant grains has been subjected to a surface modification treatment comprising the successive steps of suspending propellant grains in water to prepare a slurry, adding an organic solvent to the propellant grains before, after and/or during the preparation of the slurry, mixing the slurry that comprises water and organic solvent for a period of 120 minutes or less, lowering the concentration of organic solvent, removing organic solvent, and drying the propellant grains to remove water; wherein part of the propellant grains has not been subjected to the surface modification treatment.

US12723826 - Recoil spring abutment for a slide of a modular handgun

A recoil spring abutment for a slide of a pistol, the slide including slide grooves on both sides, and the recoil spring abutment being designed to be insertable and mountable in the slide and includes a preferably essentially semi-cylindrical base body having at least partially continuous guide rails on both sides, and an essentially circular step on a rear side for accommodating a recoil spring assembly. The invention also relates to a modular slide for such a recoil spring abutment, as well as to a slide cover sleeve, which may be mounted on the slide by means of the latter, and to the slide cover sleeve itself.

US12723827 - Staked bolt carrier for a firearm

A bolt carrier assembly for a firearm, including a bolt carrier and a gas key, the gas key having at least one hole along a median plane for receiving a fastening element, and the hole including a bore extending along the hole axis and through a central point and a recess in the upper region. The gas key includes a region of minimal wall thickness, and the gas key is fastened to the bolt carrier by means of at least one fastening element, where for securing the fastening element at least one staking is formed on at least one side wall of the gas key that is spaced apart from the region of minimal wall thickness.

US12723828 - Mechanism disassembly device for weapons with bolt mechanism

Disclosed is a mechanism disassembly device for weapons with a bolt mechanism, which allows the mechanisms to be removed and installed from the body with one hand, without a button.

US12723829 - Trigger mechanism

A trigger mechanism, including a trigger having a trigger shoulder; a trigger sear having a trigger sear shoulder, and wherein the trigger and the trigger sear are positioned such that at least a portion of the trigger shoulder is able to at least partially contact at least a portion of the trigger sear shoulder; a hammer sear having a hammer sear shoulder; a hammer having a hammer shoulder, and wherein the hammer and the hammer sear are positioned such that at least a portion of the hammer shoulder is able to at least partially contact at least a portion of the hammer sear shoulder; and a trigger bar, wherein if the trigger is rotated, the trigger releases the trigger sear, which, urges the trigger bar, which, rotates the hammer sear, which, releases the hammer.

US12723830 - Harmonically balanced firearm suppressor system

A suppressor system of a firearm is provided. The suppressor system comprises a plurality of shims; a casing having a proximal end and a distal end; a first endcap coupled to the proximal end of the casing; a removable baffle disposed within the casing; a second endcap coupled to the distal end of the casing; and a plurality of adjustable weights coupled to the second endcap. The adjustable weights and shims of the suppressor system are configurable to modify the vibration harmonic waveforms of a barrel of the firearm once a bullet is fired. As a result, both consistency and accuracy for rifles or pistols to which the suppressor system is attached are improved.

US12723831 - Measuring pressure for firearm accessories

A measurement adapter may include a body, a first attachment interface configured to attach the measurement adapter to a barrel of a firearm, and a second attachment interface configured to attach the measurement adapter to a firearm accessory. A channel may extend between the first attachment interface and the second attachment interface through the body. The measurement adapter may also include a third attachment interface configured to attach the measurement adapter to a sensing device and to provide a sensor of the sensing device access to the channel.

US12723832 - Reverse thruster muzzle brake for firearms

The present disclosure presents a muzzle break for a firearm having two portions, each comprising corresponding curved baffles, a semicircular channel running the length of the brake, circular inserts, and clamping screw receptacles. Inserts for the bore hole where the gas pressure is highest are inserted into the portions before assembly, and each half of the brake comprises a machined clearance, such that when the brake halves are assembled there is a split machined clearance over the firearm barrel outside diameter. The two halves are fastened together, with alignment pin inserts inserted into machined slots before assembly, and the inner portion of the interior channel is threaded to mate with the threading on a firearm barrel. The muzzle brake is mounted to the firearm barrel by threading the inner portion of the interior channel of the brake onto the barrel to the point of the split machined clearance. Two clamping screws are used to clamp down the barrel end of the brake inner diameter onto the barrel outer diameter to secure the brake to the barrel.

US12723834 - Training firearm

The present invention relates to a training firearm and more specifically, to a training firearm that mimics the trigger mechanism of real firearms. The training firearm comprises a frame, a break arm, a movable magnate, a frame magnet, a trigger, a reed switch and a shot indicator. On application of force, the trigger pushes the break arm to move the movable magnate closer to the reed switch. Once the magnetic field of moveable magnate is detected by the reed switch it turn on the shot indicator to shoot a laser.

US12723837 - Firearm accessory mounting system

An accessory rail mounting system for a firearm comprises an elongated stock defining a downwardly open magazine well cavity, and a magazine well insert comprising an elongated body including a mounting portion and elongated coupling rail cantilevered from the mounting portion. The mounting portion is configured for detachable mounting to a bottom surface of the stock at the magazine well cavity. Threaded fasteners may be used for mounting. The mounting portion includes an elongated magazine aperture configured to receive an ammunition magazine therethrough and latching feature configured to engage a latch of the magazine to releasably retain the magazine in the firearm. The coupling rail is configured to detachably couple and mount a firearm accessory thereto. The coupling rail may have numerous rail configurations compatible with mounting interfaces of various types of firearm accessories, such as bipods, tripods, and other accessories. Mounting portions may be varied to accept different magazines.

US12723838 - Retention system for grip attachment

In various embodiments, an apparatus to operate with a firearm grip is provided, in which the firearm grip includes two openings, including a magazine receptacle and an aftly-positioned additional opening, the openings partitioned by a wall, the apparatus comprising: a retention system insertable into the aftly-positioned additional opening, the retention system including: a drive section; and an expansion section, driven by the drive section, and configured to restrict expansion to direction(s) that are not toward the wall. Other embodiments are disclosed and/or claimed.

US12723839 - Barrel nut handguard system

A barrel nut handguard system can include a handguard with a sidewall defining a bridge opening extending to a handguard interior, a barrel nut defining a registration groove around a periphery of the barrel nut, and a connector bridge in the bridge opening so that a contact surface engages the first registration groove. A fastener extending between the connector bridge and handguard can be tightened so the barrel nut is clamped between the contact surface and the handguard interior. The contact surface can fit between walls of the registration groove and prevent fore to aft sliding of the handguard relative to the barrel nut. The barrel nut can include tool lands allowing tooled rotation of the barrel nut relative to a receiver of a firearm to secure a barrel to the receiver with the barrel nut, without requiring rotational indexing of the barrel nut relative to the receiver.

US12723843 - Optical sight and information display method

An optical sight is attached to a gun for use, including: an optical system, allowing a user to visually recognize a target serving as a sight target; a housing, accommodating the optical system; and an information display part, displaying information toward the user. The information display part is installed within the housing together with the optical system, so as to display the information around a field of view that the optical system allows the user to perform visual recognition.

US12723855 - Practice weighted insert for firearm magazine

A weighted safety-insert for a magazine of a firearm. The safety-insert includes a body and a slidable portion. The body includes a protrusion extending downwardly from a bottom surface, and a channel extends within each of first and second side walls. A pair of flanges extend outwardly from the side walls, adjacent the bottom surface. The slidable portion, includes a top surface, and first and second side wall, each having an upper end disposed higher than the top surface and terminating in an inwardly facing lip. The slidable portion is adapted to engage the body such that the top surface of the slidable portion rests against the top surface of the body, the inwardly facing lips being slidably disposed within the channels in the side walls of the body or a prismatic protrusion of the slideable portion being slidably disposed in a channel in the top side of the body.

USD1145952 - Handguard for a rifle

US12716665 - Firearm

A firearm having a straight pull bolt action operating mechanism. The firearm has a lower receiver housing a trigger assembly, an upper receiver having a longitudinal axis, and a bolt carrier assembly within the upper receiver. The bolt carrier assembly has a bolt carrier, a bolt, a follower element, and an operating component. The bolt is received by the bolt carrier and is configured to rotate about the longitudinal axis. The operating component is configured to be manually operated by a user.

US12716666 - Firearm

The present invention relates to a firearm, which includes a receiver and a barrel mountable to the receiver. A slide is mountable to the receiver so as to be movable between an open position and a closed position. A locking element is operatively associated with the barrel. The locking element is displaceable between an inactive position and an active position whereby, when the locking element is in the active position, the locking element engages the slide such that movement of the slide towards the open position is inhibited.

US12716667 - 3D printed bolt receiver with reinforcing blade and picatinny rail

An improved receiver such as for bolt action firearms has an integrally formed reinforcing feature or blade situated below the ejection port. This blade extends longitudinally from the proximal receiver bridge to the distal receiver bridge and may continue into the barrel boss region. Functioning like an arch bridge, the reinforcing blade significantly enhances the structural rigidity of the bolt receiver at its weakest point around the ejection port, reducing flexion during firing and minimizing fatigue. The blade tapers in thickness both laterally away from the receiver's centerline and longitudinally toward the distal end, optimizing material usage while maximizing structural benefits. The bolt receiver is preferably fabricated as a single, monolithic structure using metal 3D printing technology, which allows for the integral formation of additional features such as a Picatinny rail on the top surface and a recoil lug at the distal end portion. These integrated components collectively improve the receiver's functionality, durability, and versatility.

US12716668 - Firearm receiver systems offering a fixed barrel arrangement and pressure relief capability

A firearm receiver system comprises a receiver and a handguard. The receiver includes a front mounting body and a central bore configured for having a bolt carrier slidably disposed therein. The central bore includes a barrel-receiving receptacle at least partially located within the front mounting body. The handguard includes a handguard mounting body receptacle at a first end portion thereof. The front mounting body includes a plurality of interior surfaces each matingly engaged with a corresponding one of a plurality of exterior surfaces of the handguard mounting body receptacle. The receiver and the handguard may unitarily-formed body. The receiver may be configured for accommodating a barrel extension. The front mounting body may be configured for providing a fixed-barrel receiver system. The receiver may accommodate a pressure relief body for enabling the receiver to exhibit pressure relief functionality in the event of an over-pressure event within the receiver.

US12716669 - Ambidextrous bolt release mechanism for firearm

A firearm with ambidextrous bolt release mechanism includes a barrel and a bolt slideably mounted in the receiver for axial movement between forward closed breech position in battery with the barrel and a rearward open breech position. A recoil spring biases the bolt forward. A side-mounted bolt catch lever is configured and operable to selectively hold the bolt in the open breech position, and disengage the bolt to reclose the breech when manually actuated. A transversely movable actuator plunger allows a user to release the bolt from the side of the firearm opposite the bolt catch lever side. The plunger comprises an inclined camming surface which slideably engages a mating inclined camming ramp on the lever. Wedging action applied to the bolt catch lever by the plunger rotates the lever about its pivot axis to disengage and release the bolt.

US12716670 - Adjustable gas system

Disclosed is a firearm gas system including a gas block having a body with gas passageway for alignment with a barrel gas port. A gas tube has a gas inlet in a forward portion thereof and is axially variably positionable in at least partial alignment and disalignment relative to the gas passageway to thereby adjust gas flow.

US12716672 - Machine gun trigger assembly

A trigger lever assembly includes a link rotatable between a first position and a second position. The link has a first leg extending from an axis of rotation to a first end portion and a second leg extending from the axis of rotation to a second end portion. A trigger lever is mounted to the first end portion of the link and is rotatable between a blocked position and an unblocked position. The trigger lever is biased toward the blocked position. In the blocked position, a second end portion of the trigger lever contacts a first protrusion on the link. On the other hand, when the trigger lever is in the unblocked position, the second end portion of the trigger lever abuts a second protrusion on the link. The assembly can be part of a spade grip assembly or part of a complete machine gun.

US12716673 - Synthetic trigger system

The present disclosure provides systems and techniques for a trigger system that can be implemented in a gun. The trigger system may include a trigger body affixed to a pivot, a trigger detent affixed to the pivot, and a detent biasing device configured to bias the trigger detent away from the trigger body such that a detent surface protrudes from the trigger body. The trigger detent may be moveable along a displacement path, and an obstructing surface that is configured to remain substantially stationary relative to the trigger detent may be located in the displacement path of the trigger detent. The trigger detent may be configured to contact the obstructing surface while moving along the displacement path, move linearly away from the obstructing surface by compressing the detent biasing device, and move past the obstructing surface based on a threshold amount of force being applied to the trigger body.

US12716675 - Firearm training system and method utilizing distributed stimulus projection

Systems and methods are disclosed herein to improve efficiency and effectiveness in firearms and tactical training, at least in part by selectively generating images onto external target elements. One or more portable devices are selectively mounted with respect to selected ones of the external target elements, which may be fixed in position or mobile as the application demands. Each device includes a housing accommodating and configured for optical projection of light from an array of laser sources and diffractive optical elements. A device controller directs the projection of light from one or more of the laser sources according to a programmed dynamic target stimulus arrangement. The device controller may be individually and manually programmed or commanded in some embodiments, but alternatively a master controller may be implemented to coordinate light projections from an array of devices to provide any number of desired scenarios for neurological and/or physiological stimulation of users.

US12716683 - Muzzleloader power cell with primer

Muzzleloader systems including a pre-packaged propellant charge with a primer and receptacle. The muzzleloader system may include a propellant containment vessel separate from the primer and the projectile and that doesn't contact with the projectile until assembly. The muzzleloader may be rear loading, with a constriction portion forward of the breech chamber. The propellant containment vessel may include a body portion having a forward opening, with a propellant charge disposed therein and a cap portion that is crimp rolled within the mouth of the vessel to seal the forward opening. The closed end of the propellant containment vessel may define a primer receptacle configured to receive the primer. The receptacle may define a depth that is less than the primer height so that, when inserted into the receptacle, the primer extends rearwardly beyond the containment vessel. The muzzleloader system may be configured to fire only specifically configured propellant containment vessels.

US12716684 - Slider mechanism for collapsible firearm stock

A device may include a proximal end and a distal end, an internal cavity of the device is defined between the proximal end and the distal end. The device may include a slider panel defining a channel and a biasing mechanism disposed in the internal cavity, the biasing mechanism configured to bias the slider panel. The device may include a lock pin disposed in the internal cavity and configured to contact the biasing mechanism. The device may include a release pin extending through the lock pin, wherein: an end portion of the release pin extends into the channel, the release pin is configured to travel along a path defined by the channel in response to a movement of the slider panel; and the release pin is configured to cause the lock pin to transition from a first position to a second position in response to the movement.

US12716686 - Vertically adjustable belt loop

A holster support assembly for supporting a holster configured for receiving and withdrawing a handgun. The holster support assembly is configured for supporting a holster on a user's belt and comprises a belt engaging member comprising: a column portion and at least one belt loop portion; wherein the holster attachment portion comprises: a central slot; a plurality of pairs of diametrically opposed recesses on the rear face, defining a plurality of ride height positions.

US12716688 - Firearm-scope-attachable diopter lens device

A firearm-scope-attachable diopter lens device is provided. The device is comprised of an eyepiece-mounted optical accessory configured to affix securely over the eyepiece of a standard firearm scope without requiring any permanent modification to the scope itself. The device comprises a housing with at least one optically-aligned diopter lens, available in a range of diopter strengths to correct myopia, hyperopia, or astigmatism. In certain embodiments, the lens is installed in a removable cartridge that interfaces with the housing via a fastener such as a magnetic ring, twist-lock, or bayonet mechanism. Selective lens tinting may be applied to enhance contrast and reduce glare in varying light conditions. An optional micro-adjustment ring concentrically aligned with the lens permits fine diopter calibration in increments of ±0.25 diopters. A protective flip-up cap with a silent hinge mechanism and optional locking feature is integrated to shield the lens from debris when not in use.

US12716689 - Firearm sighting device and system

Systems, devices and non-transitory mediums that may display (a) a list of weapons or ammunition, allowing the user to select a type of weapon or ammunition; (b) a reticle selection screen allowing a user to select the type of reticle to be displayed; (c) adjustment controls allowing the user to adjust the positioning of the display reticle; (d) adjustment controls allowing the user to mark a position of a firearm reticle; (d) a range-to-target screen allowing the user to directly input range information or to employ a range finder; (e) a keypad allowing a user to enter a height estimate for the target; a scaling control screen to allow the user to input relative height information of the target; (f) an environmental information page allowing the user to enter the environmental factors; or (g) an optimized aim point or adjusted reticle based on such information.

US12716690 - Accessory mounts

A system includes a mounting portion and an accessory portion. The mounting portion includes an alignment projection protruding from a first surface, a mount-side recess formed in the first surface and offset from the alignment projection, and a mount-side object disposed in the mount-side recess. The accessory portion includes a second surface forming an alignment recess configured to receive the alignment projection of the mounting portion, and an accessory-side object disposed in the accessory-side recess. The accessory-side object and the mount-side object are configured to couple to removably secure the accessory portion to the mounting portion.

US12716692 - Portable ballistic shield with integrated weapon bracket

In one example, a portable shield includes a first cover, a second cover, a panel, a panel retention system, and a weapon support bracket. The second cover is configured to couple to the first cover and thereby from a cavity between the first and second covers. The panel is configured to fit within the cavity and to resist penetration of a weapon-fired projectile having a kinetic energy greater than 500 foot-pounds. The panel retention system is coupled to the first or second shield cover and configured to bear the load of the panel and to hold the panel in a fixed place within the cavity. The weapon support bracket is coupled to the panel retention system and has a bracket arm selectively moveable between an extended position and a retracted position. The extended position extends the bracket arm beyond respective edges of the first and second shield covers. The bracket arm provides a surface configured to support the forend portion of a firearm.

US12710241 - Firearm receiver assemblies

A firearm receiver assembly includes a receiver body with a plurality of cavities and a plurality of rails. Each of the plurality of rails is disposed in one of the plurality of cavities. Each of the plurality of rails includes at least one retaining feature for engaging the corresponding cavity.

US12710242 - Firearm locking device

A device including a body coupled to a magazine receiving area of a firearm and a locking unit that locks a firearm to the body of the device.

US12710247 - Firearm grip

A firearm grip has an elongated body having an upper end having an upper attachment facility configured to attach to a firearm, the elongated body having an opposed lower end having a second attachment facility, a palm rest element having a base element having a third attachment facility configured to removably connect to the second attachment facility, the palm rest having a palm support element connected to the base element, and the palm support element defining a central aperture receiving the base element and having an upper surface encompassing the base element. The palm support element may be pivotally connected to the base element. The palm support element may be connected to pivot about a pivot axis transverse to a major plane of the firearm. The pivot axis may be at a level below the opposed lower end of the elongated body.

US12710248 - Apparatus for remotely adjusting scope magnification

An assembly allows for remote control of magnification of a scope of a firearm, the assembly comprising a housing for an adjustable-magnification scope to be mounted thereto, a motor carried by the housing and coupled to a magnification adjuster ring of the scope for causing selective rotation thereof, and a battery carried by the housing and configured for providing electrical power to the motor and to accessories carried by the firearm. A switch actuated by a user controls operation of the motor.

US12710249 - Turret with a zero stop

In one embodiment, the disclosure relates to a turret for a firearm. In another embodiment, the disclosure relates to a turret zero stop.

US12710250 - Dovetail reflex sight and interface for mounting to a firearm

To allow a reflex sight to be mounted to the slider of a handgun and removed without the need for tools, an adapter shoe may be secured to the slider to provide an interface between an optics-ready recess of the slider and a mounting element that forms part of the reflex sight assembly. The adapter shoe may provide a dovetail track that engages complementary dovetail features of the mounting element. A push button retention mechanism may be biased to lock the mounting element within the adapter shoe. Actuation of the push buttons may retract the retention mechanism and allow the reflex sight assembly to slide out of the dovetail track.

US12710251 - Sight and accessory mount assembly for a firearm

A sight and accessory mount assembly for a firearm having a rail includes a sight mount configured to carry a sight, and an accessory mount configured to carry an accessory. The accessory mount extends rearwardly from, and is pivotally connected to, the sight mount when the sight and accessory mount is attached to the firearm rail. The accessory mount is rotatable between a first end position and a second end position relative to the first sight mount, wherein in the first end position the accessory mount and an accessory that may be carried by the accessory mount are aligned with the sight mount and a sight that may be carried by the sight mount, and in the second end position the accessory mount and an accessory that may be carried by the accessory mount are pivoted away from the sight mount.

US12710254 - Training apparatus including a weapon

Training apparatus ( 1 ) for at least one user ( 2 ), including a weapon ( 3 ) and consisting of a device for detecting a hit and a display device ( 6 ) for displaying virtual targets ( 13 ), wherein: the display device ( 6 ), worn by the user, takes the form of an augmented reality (AR) device, which visually displays to the user ( 2 ) at least the target ( 13 ) to be hit; the weapon ( 3 ) takes the form of a firearm, which fires at least one projectile ( 7 ); and the projectile ( 7 ) is detected by at least one laser ( 9, 11 ), evaluated and visually displayed on the display device ( 6 ).

USD1142810 - Firearm

USD1142811 - Firearm upper assembly

US12703066 - Suppressor assembly, toolset, and methods for assembling and disassembling

Assemblies, suppressor assemblies, firearms, tool sets, methods, and/or the like are provided. In some embodiments, a tool set for assembling and/or disassembling a suppressor assembly may include a first wrench and a second wrench. In some embodiments, the first wrench includes one or more teeth configured to engage a plurality of annularly arranged protrusions disposed at or proximate a distal end of a suppressor assembly, the plurality of annularly arranged protrusions defining recesses therebetween. In some embodiments, the second wrench includes one or more wrench engagement surfaces configured to engage one or more corresponding suppressor engagement surfaces disposed at or proximate a proximal end of the suppressor assembly.

US12704335 - Handgun and magazine therefor

A handgun has a grip portion defining a magazine well, the grip portion having a web region configured to be grasped between a thumb and an index finger, a forward portion of the web region defining a first width. The grip portion also has a palm region configured to be grasped by a user's palm, the palm region defining a second width greater than the first width. A magazine is configured to be received in the magazine well and includes a hollow magazine tube with a single-stack portion and a double-stack portion positioned below the single-stack portion. For example, front portions of the opposite tube sidewalls have a stepped shape between the upper tube end and the double-stack portion.

US12704336 - Heat shield for firearm suppressors and method

A heat dissipation promoting ventilated protective guard for a firearm suppressor also known as a moderator can include a substantially cylindrical cage shaped body surrounding an inner void that can contain the suppressor. In inwardly projecting beveled stop-surface on the guard bears against a corresponding beveled shoulder on the suppressor to limit axial movement. A snap-ring and wave spring bias the guard against the shoulder. Slits and vents in the mounted guard allow air to pass over the suppressor and prevent contact by a user with a dangerously hot suppressor.

US12704337 - Firearm magazine release lever apparatus and related methods

A magazine release lever apparatus is provided having an engagement portion and a lever arm. The engagement portion is to engage a portion of an ammunition magazine to secure the ammunition magazine to the firearm. The lever arm extends from the engagement portion. The lever arm is pivotable about a pivot axis to move the engagement portion between a magazine securing position and a magazine release position. The lever arm is to be adjustably mounted to the firearm to permit adjustment of a position of the engagement portion relative to the pivot axis.

US12704338 - Trigger device

A trigger device for activating a firing mechanism is described. The trigger device comprises a housing, a sear, and a trigger. The sear is pivotally mounted on the housing via a sear pivot pin. The trigger is pivotally mounted on the housing via a trigger pivot pin. The trigger comprises a trigger extender. The trigger extender inhibits unloading the sear until the trigger is rotated from a ready position.

US12704339 - Sear assembly for weapons

A sear assembly for a weapon, the weapon comprising a hammer adapted to contact with the sear assembly and a trigger disconnected from the sear assembly, the sear assembly comprises a sear for mechanically engaging a sear surface on the hammer, a lever mechanically coupled by one end to the sear, the lever comprising a contact surface that causes the rotation of the sear, an actuator that actuates the lever by means of a cam, and a trigger sensor that is configured to determine if the trigger is pulled. In this regard, the trigger sensor is a coil. The sear assembly comprises a firing state and a safe state.

US12704340 - Firearm sound suppressor with peripheral venting

An apparatus and methods are provided for a suppressor to be coupled with a muzzle end of a barrel of a firearm to reduce muzzle blast and muzzle flash. The suppressor comprises a housing having a proximal end and a distal end. A front portion within the housing comprises a series of cylindrical gas expansion chambers for attenuating the temperature and energy of propellant gases accompanying a projectile fired from the firearm. An annular gas expansion chamber surrounds the cylindrical gas expansion chambers and directs a portion of the propellant gases from a rear portion of the suppressor to peripheral vents disposed at the distal end. Lateral chambers within the rear portion deflect and rebound a portion of the propellant gases before passing them into the annular gas expansion chamber. Ledges within the annular gas expansion chamber direct the propellant gases distally through suppressor toward the peripheral vents.

US12704341 - Suppressor baffle

A suppressor baffle includes a cone portion expanding along a central axis from a proximal end defining a projectile opening to an open distal end having an outer rim. The projectile opening is in an entrance plane oriented obliquely to the central axis. A first volume between a first side of the cone portion and a central plane that includes the central axis is smaller than a second volume between an opposite second side of the cone portion and the central plane. At least part of the outer surface of the second side of the cone portion has a convex profile as viewed along the central plane from a side of the suppressor baffle. In another example, a first part of the cone is axially offset from an opposite second part of the cone, resulting in a curved projectile opening profile and a curved outer rim profile.

US12704342 - Electronically controlled recoil positioning (ECRP) system for firearms

An Electronic Controlled Recoil Position (ECRP) unit is muzzle-mounted on a firearm and is designed for nearly real-time correction of the firearm's recoil. This correction can maintain a shooters aim on target or else nearly remove recoil for easier control of the firearm during full or semi-automatic fire. The ECRP unit is primarily designed as a cylindrical body that attaches to the muzzle of a firearm barrel via threaded or snap-on connection. The unit features an internal bore aligned with the barrel to allow projectiles to pass through unimpeded.

US12704345 - Combat training system

A combat training system for carrying out and monitoring at least one shooting practice and combat scenarios, comprising: at least two components, with a first component being a firearm and a second component being a target object; a device for sensing position information of each of the at least two components; device for sensing spatial orientation information at least for the at least one firearm of the at least two components; and an information processor, in which position information of the at least two components and the orientation information of the at least one firearm is processed and transformed into at least result information. The at least two components each have a clock, which are time-synchronized with each other and each generate coded time signals with a component identifier which individualizes the respective component, and an event sensor is provided on each of the at least two components.

US12704346 - Training system

A training system for using a firearm is provided. The training system has a simulacrum firearm having a trigger assembly, electro-stimulators engaging a user's body for producing an electrical stimulation, shot detectors for detecting an actuation of the trigger assembly, a grip detection unit for detecting modes of gripping the simulacrum firearm by the user, and a command and control unit operatively connected to the simulacrum firearm and to the electro-stimulators to control the electro-stimulators on actuation upon a detection of an event of a fired a shot by the shot detectors The command and control unit commands intensity, duration, timing and type of electrical stimulation, namely electric current, emitted by the electro-stimulators as a function of a detection performed by the grip detection unit.

US12704351 - Closable pistol stabilizer assembly

A pistol stabilizer assembly includes a chassis that has a pistol mounting portion configured to securely support a pistol therein, and a buttstock movingly coupled to the chassis. In a closed orientation, the buttstock is moved relative to the chassis to couple with the pistol mounting portion, and if a pistol is mounted in the pistol mounting portion, to conceal the pistol. In an extended orientation, the buttstock is moved relative to the chassis away from the pistol mounting portion to expose operating portions of the pistol.

US12704356 - Firearm accessory mounting structure

A firearm accessory and associated components and methods. The firearm can be a firearm sight, such as a red dot type sight. The firearm accessory includes a base configured to mount to at least first and second different mounting adaptors to permit selective mounting of the firearm accessory to a firearm via the first mounting adaptor or the second mounting adaptor.

US12704357 - Mounting system for mini red dot sights

A mounting system for securing a viewing optic to a firearm utilizes an oblong dovetail connection component having a first end, a second end, and a contoured perimeter forming a dovetail profile. The viewing optic has a bottom surface comprising a mortise slot open at a first end to receive the oblong dovetail connection component and closed at a second end, the viewing optic further comprising a fastening area on a side of the viewing optic, the fastening area having a first securing structure. A fastening element having a second securing structure, wherein the first and second securing structures correspond to one another and facilitate securing the fastening element to the fastening area.

US12698943 - Trigger assembly with safety features

Provided are a trigger assembly, firearm, and various methods and components. An example assembly includes a lower trigger body comprising a trigger lever; a disconnector rotatable relative to the lower trigger body; a trigger tower rotatable relative to the lower trigger body and the disconnector, the trigger tower defining a trigger tower hook; and a hammer defining a hammer sear hook configured to engage the trigger tower hook to hold the hammer in a cocked position. In response to application of a force to the trigger lever, the lower trigger body may rotate and cause the trigger tower to rotate to release the trigger tower hook from the hammer sear hook.

US12698944 - Thermoacoustic heat exchanger suppressor

A silencer core for suppressing and dissipating at least one of a sound, a flame, or a quantity of heat of a projectile fired from a firearm includes a thermoacoustic organic structure (TOS) extending along a central axis from a first end to a second end. The TOS defines a central bore extending along the central axis from the first end to the second end. The central bore enabling the projectile to pass through the TOS when fired from the firearm. The TOS also defines a network of interconnected passages or a mesh configured to move at least one of combustion gases, heat, or sound from the central bore to an outside diameter of the TOS. The TOS has a density between 1.5 g/cm 3 to 4 g/cm 3 .

US12698946 - Adjustable firearm stock with passive tensioning mechanism

Embodiments of the disclosure relate to adjustable stocks for firearms and methods for installing an independently sprung tensioning mechanism. The adjustable stock comprises a stock body attached to a buffer tube, with a lever-operated tensioning mechanism. The mechanism includes a tensioning block with fins to grip the buffer tube, an indexing pin, and a retaining pin. When the lever is depressed, the tensioning block and indexing pin disengage, allowing longitudinal adjustment of the stock on the buffer tube. The tensioning block applies upward pressure on the tube, compensating for rotational tolerances during assembly. Both the tensioning block and indexing pin move independently when engaging with the buffer tube but move together when disengaging. The indexing pin is biased towards the buffer tube by a spring, while another spring biases the tensioning block. The lever engages the retaining pin to retract both the indexing pin and tensioning block.

US12698948 - Aiming device for firearm

An aiming device for a firearm comprising a housing and a near infrared illuminator. The near infrared illuminator is positioned in the housing and is configured to output near infrared light with adjustable beam divergence to provide a field of illumination that is adjustable. The near infrared illuminator includes a divergence adjustment input positioned on an upper side of the housing that is movable by a user to adjust the beam divergence.

US12698951 - Method for determining position of a laser point applied in a firearm training simulation system using infrared lasers

A method to detect, identify and determine the position of laser points from infrared laser emitters in a firearm training simulation system. The method consists of two steps. This first step combines some common tools such as a camera with a filter switcher and edge and corner detecting algorithms in image processing to provide a fast automatic screen calibrating method. The second step is to detect laser point objects in each frame continuously captured by the camera, and then further process these objects to identify laser shots, filter out noisy objects, and eventually detect simulated shots from different laser emitters and determine the final mapped position of the shot.
