Firearms and Ammunition Patent Grants

US12594901 - Gas generator

The invention shows a gas generator comprising a pressure chamber ( 22 ) filled with compressed gas which is sealed against an environment of the gas generator ( 10 ) by a membrane ( 16 ), a solid propellant ( 30 ) received in the pressure chamber ( 22 ), and an igniter unit ( 14 ) adjacent to the pressure chamber ( 22 ). The solid propellant ( 30 ) is surrounded by a cage-type open fuel holder ( 32 ) receiving the same which protrudes into the pressure chamber ( 22 ) and is directly adjacent to the igniter unit ( 14 ). Accordingly, the pressure chamber ( 22 ) is free from solid propellant outside the fuel holder ( 32 ).

US12595701 - Manufacturing method of an intelligent anti-terrorism protective door

A manufacturing method of an intelligent anti-terrorism protective door comprises the following steps: S1, making front and rear door panels; S2, cutting the composite door core panel materials; S3, making protective door frame; S4, assembling bulletproof and explosion-proof armored composite door core panel; S5, making the door frame; S6, decorating the surface of the protective door; S7, overall assembly; S8, installing the lock; S9, packaging the protective door. The manufacturing method is simple and easy to implement, with strict control over every aspect from raw materials, production processes, to quality control during the manufacturing process, ensuring the product quality. This not only makes the product fire-proof and anti-theft, but also has explosion-proof and bulletproof properties, effectively preventing explosions and bullet attacks, greatly improving the security of the protective door.

US12595937 - Thermal management apparatus

Provided is a thermal management apparatus for use with a vehicle, the apparatus comprising a plurality of phase change heat exchange units thermally coupled with a vehicle system that requires thermal management, the plurality of phase change heat exchange units operable to remove heat from the vehicle system.

US12595981 - Braking mechanism for a gun

Braking mechanism for a gun includes a fork whose arms are abutted by supporting pins that abut on brake rollers. A breech that has vertical engagement grooves. Spring-loaded pins with compression springs are arranged against supporting pins. The body of the fork is terminated by a tapered tongue extending into a cavity which follows the fork. Behind the tongue a rod is arranged, which passes into the cavity in a sleeve. The sleeve is provided at one end with an end rod, which is provided at its face with a cylindrical ending arranged eccentrically below its center. The supporting pin is provided with a vertical elongated groove to accommodate the safety pin. In front of the trigger a locking lever of the control arm is placed. At the end is the control arm provided with a transverse beam, which is accommodated above the ending of the end rod.

US12595982 - Ambidextrous bolt release mechanism for firearm

A firearm with ambidextrous bolt release mechanism includes a barrel and a bolt slideably mounted in the receiver for axial movement between forward closed breech position in battery with the barrel and a rearward open breech position. A recoil spring biases the bolt forward. A side-mounted bolt catch lever is configured and operable to selectively hold the bolt in the open breech position, and disengage the bolt to reclose the breech when manually actuated. A transversely movable actuator plunger allows a user to release the bolt from the side of the firearm opposite the bolt catch lever side. The plunger comprises an inclined camming surface which slideably engages a mating inclined camming ramp on the lever. Wedging action applied to the bolt catch lever by the plunger rotates the lever about its pivot axis to disengage and release the bolt.

US12595983 - Diverging central bore for firearm sound suppressor

An apparatus and methods are provided for a front plate having a diverging central bore for firearm sound suppressors that improves noise and flash characteristics during firing a weapon. The central bore is disposed between a back surface and a front surface of the front plate. An untapered portion of the central bore extends from the back surface to a diverging portion that opens toward the front surface. The diverging portion includes a curvature profile configured to allow for more controlled expansion of high-pressure propellant gases exiting of the suppressor through the central bore. The curvature profile provides an included angle of the central bore that decreases secondary flash events accompanying the expulsion of propellant gases accompanying a fired bullet exiting the suppressor through the central bore. The curvature profile exhibits a cross-sectional area of the central bore that is proportional to a distance along the diverging portion.

US12595984 - Gun muzzle sound suppressor

A gun muzzle sound suppressor including a plurality of segments, wherein each segment among the plurality of segments including a cylindrical housing having an inner surface and an outer surface, wherein the each segment further includes a conical baffle fixedly attached to the inner surface of the each segment's cylindrical housing, wherein the each segment further includes a plurality of vanes fixedly attached to the outer surface of the each segment's cylindrical housing; an outer housing having an inner surface, wherein the outer housing is fitted for sliding receipts of the segments, wherein upon the receipts of the segments, the vanes contact the outer housing's inner surface; and a pair of rings fixedly attached to the outer housing, one the rings among the pair of rings being positioned muzzlewardly from a muzzleward-most segment among the plurality of segments, the other ring among the plurality of rings being positioned breachwardly from a breachward-most segment among the plurality of segments.

US12595985 - Customer-serviceable forearm assembly

A firearm forearm assembly is provided. Generally included is a forearm retainer that is a flexible component installed in the forearm, which is then momentarily deflected to admit each action bar. Once the forearm assembly is installed in the firearm, the firearm's magazine tube is introduced and prevents further deflection of the retainer, thus locking the forearm assembly together during use. As a result, the forearm assembly is easily disassembled by the user without the use of tools by deflection of the retainer and removal of the action bars. But at the same time, the integrity of the firearm is preserved during operation.

US12595986 - Correcting targeting of indirect fire

A system and method are provided for correcting targeting of indirect fire, including: acquiring values for a set of firing conditions, for each of the firing conditions determining statistical parameters of a covariance matrix of the firing conditions, including estimates of unit effects, standard deviations, and error correlations between registration and fire-for-effect (FFE) firing condition errors, wherein at least one correlation is less than one and greater than zero, acquiring a registration miss vector, generating from the statistical parameters a conditional correction matrix; and multiplying the conditional correction matrix by the registration miss vector to calculate a correction vector for FFE targeting.

US12595987 - Systems and methods for shooting simulation and training

Provided herein are systems and methods for shooting simulation of a target with a projectile. More particularly, the invention relates to virtual reality optical projection systems to monitor and simulate shooting.

US12595988 - Stitched body armor panels with offset construction

A soft body armor arrangement has a plurality of layers of soft ballistic material stacked on one another, each layer comprising a plurality of sub-layers of ballistic material. Each of the layers has a respective seam line attaching two or more respective sections of the layer. The sizes of the section are varied so that the resultant seam lines of adjacent layers are offset and spaced apart from one another, but the overall size and shape of each layer is the same. This avoids stacking and bunching of the seam lines which can cause rigidity and discomfort.

US12595989 - Multi-part shaped charge liner

The present disclosure relates to a shaped charge liner. The shaped charge liner includes a first liner portion formed a first material. The first liner portion has an apex and a skirt section that define an interior volume of the first liner portion. The shaped charge liner also includes a second liner portion formed of a second material. The second liner portion is coupled to the first liner portion such that the second liner portion is an edge of the interior volume.

US12595990 - Main charge holder for electro-explosive devices (EEDs)

The header of an EED is redesigned to increase stiction forces to better hold the main charge throughout deflagration. The header includes a main charge holder, integrally formed or as a discrete component, that has internal structure that is press fit to a complementary outer surface of the main charge. The contact area between the internal structure and the main charge being greater than the contact area between a cylinder that circumscribes the internal structure (the uniform cylindrical shape of a typical EED contact area of π*D*L) to increase stiction forces between the main charge holder and the main charge. For a given diameter and length, the inclusion of the internal structure will reduce the mass of the main charge.

US12595991 - Gas generator

A gas generator includes: an ignition device including an igniter, an igniter holding portion having a tubular shape and being configured to hold the igniter and a fixing portion made of resin and being configured to fix the igniter to the igniter holding portion; and a case having a bottomed tubular shape and being configured to accommodate a gas generating agent which combusts by actuation of the ignition device, the case being made of resin and including a side wall portion with a base end side being connected to the fixing portion, and a closing end portion configured to close a tip end side. The case includes an inclined surface extending obliquely with respect to an axial direction of the case on the tip end side, and a fragile part formed at an edge portion excluding at least a base end portion of the inclined surface.

US12595992 - Arrowhead

An arrowhead, in accordance with the present invention, includes an apex, and a first pair of blades fixed about an axis of the arrowhead, each of the preferably coplanar blades containing an edge defining a single-bevel edge that transitions to a double-bevel edge along the periphery of the arrowhead. The arrowhead may further contain a smaller second pair of blades fixed about the axis, each of the second pair of blades spaced apart from a primary blade, each of the second pair of blades extending along and fixed to the arrowhead along the axis.

US12595993 - Safety systems for commercial blasting operations

The safety systems for commercial blasting operations include wireless transmitter system(s) configured to send command signals wirelessly to wireless devices that are configured for wireless electronic blasting (web). The system also includes disable antenna(s) that define deactivation zone(s): vehicle/personnel presence detector system(s) including detectors that define detection zone(s), and/or RFID scanner system(s) with reader antennas that defined scanner zone(s); and a safety control system in electronic communication with the wireless transmitter system(s), and the vehicle/personnel presence detector systems and/or the RFID scanner systems, wherein the safety control system is configured to control the wireless transmitter systems to send wireless disable command(s) to disable the wireless devices that are within the deactivation zones, and/or to control alarm system(s) to generate alarms, in response to a vehicle/person being detected in the detection zones and/or a wireless device being detected in the scanner zones.

US12596265 - Aiming device with a diffractive optical element and reflective image combiner

A diffractive optic reflex sight (DORS) is provided for aiming devices in which a virtual image, such as a reticle, is produced and appears in the distance of a user's view when looking through the reflex sight. A light source illuminates a diffractive optical element (DOE) that includes a modulation pattern that generates a patterned illuminations corresponding with the virtual image. A reflective image combiner then reflects the patterned illumination so that the virtual image appears in the distance of the viewer's view. The DORS optical design system is mechanically and optically stable for precision aiming across a range of environmental conditions and in different use scenarios or applications including use in rapidly changing temperatures, varying light conditions, and a wide range of user proficiencies. The DORS optical design system is a readily manufacturable aiming and sighting device for a wide range of applications from handguns to astronomical telescopes.

US12596371 - System and method for interception and countering unmanned aerial vehicles (UAVS)

Systems, devices, and methods for identifying a target aerial vehicle, deploying an interceptor aerial vehicle comprising at least one effector, maneuvering the interceptor aerial vehicle to a position to engage a target aerial vehicle, deploying the at least one effector to intercept the target aerial vehicle, and confirming that the target aerial vehicle has been intercepted.

USD1121761 - Shotgun receiver

US12589315 - Virtual and augmented reality shooting systems and methods

Provided herein are systems and methods for training, maintaining and using skills for shooting a target with a projectile. More particularly, the invention relates to virtual and/or augmented reality, augmented reality, mixed reality and consensual reality systems and methods to train and maintain shooting skills in military, law enforcement, competition and sporting settings, environments and missions.

US12589317 - Portable gaming console

A portable gaming console and method of use, the gaming console including: an enclosure; a controller housed in the enclosure and including a processor and a non-transitory computer readable medium; a main display housed in a lid of the enclosure and in data communication with the controller; and a sub-display housed in the enclosure and in data communication with the controller, wherein the sub-display is configured to be folded out of the enclosure, wherein the gaming console is configured to run a game using the controller and to display the game on the main display and supplemental game data on the sub-display.

US12589469 - Leveling knob system and mechanism

A leveling system for a clamping device can include a base having a top, a bottom, and a plurality of sides; and a leveling knob positioned on one of the plurality of sides of the base and comprising a spring, a pin, and a knob connected at an outer end of the shaft. The spring can be compressible when the knob is pulled away from the base. In a locked configuration, the leveling knob can be at a neutral angle and in a home position with the pin positioned within the base. The pin can be removable from the base when the spring is compressed. The leveling knob can be twistable in at least one of clockwise and counterclockwise rotations when the pin is removed from the base.

US12589933 - Adaptable foam grid system for insertion into protective case

An omni foam grid system for insertion into a protective case has a grid plate sandwiched between a lower perimeter frame, or series of stepped pegs or peg/holster combinations, and an upper perimeter frame. The grid plate has a lattice that forms round or square holes, into which round or square pegs are frictionally inserted. The lower perimeter frame or pegs position the grid plate above the bottom of the case, such that when an object such as a gun or drone is pressed into the invention, the pegs under the invention depress into the negative space, leaving undepressed pegs on all sides of the object to prevent lateral movement during transport in the case. The lid of the case closes upon the object, thereby securing and protecting it with foam on all sides.

US12590515 - Reusable perforating gun system and method

A tool string includes a perforating gun, a first electrical connector defining a receptacle and includes a first electrical contact positioned in the receptacle, and a sub including a sub housing including first end, a second end opposite the first end, and a central passage extending between the first end and the second end, and a bulkhead connector positionable in the central passage to form a pressure barrier along the central passage, the bulkhead connector including an outer housing defining a radially outer periphery of the bulkhead connector, and a second electrical contact positioned along the outer periphery of the bulkhead connector and configured to establish radially directed electrical contact with the first electrical contact of the first electrical connector irrespective of the angular orientation of the second electrical contact relative to the first electrical contact.

US12590771 - Large-caliber gun having a breech assembly with multiple chambers

A large-calibre firearm including a breech assembly including a breech block rigidly connected to a firearm barrel, a breech support movable in axial translation relative to the breech block and coupled to a breech head, the assembly further includes a plurality of loading chambers, a mechanism for moving the chambers, configured to support the chambers and successively place one of the chambers in a firing position, and at least one other chamber in a supply position, in which the at least one chamber is able to receive ammunition via its rear end, and a locking mechanism configured to move the breech head and the chamber placed in the firing position between an unlocked position and a locked position, in which the chamber is closed off at its rear end by the breech head and opens out at its front end into the firearm barrel.

US12590772 - Method and system for sensing, monitoring, logging and transmitting events that is assembled on a firearm

An IoT system for sensing, monitoring, logging and transmitting events that is assembled on a firearm and the holster of said firearm, made up of at least two IoT modules, wherein a first IoT module is located in the firearm and a second IoT module is located in the holster of the firearm. Said system further includes sensing, logging, storing, and transmitting the real-time (or near-real-time) location of the firearm and the user thereof in an ongoing manner, so as to be able to reconstruct the path of the firearm of interest over time. Transmitting the events selected from the set including data indicating the state of the firearm (holstered or drawn), battery charge of both modules, position of the firearm and the bearer thereof; direction of the firearm, firearm fired and the absolute orientation of each shot. In the presence of any of said events, storing in a non-volatile memory a preset time before and after the data of all the sensors before, during and after the event. Said log includes the encoding of the sensed data, the interleaving of said data and the encryption thereof.

US12590773 - Magazine disconnect mechanism

A firearm has a magazine disconnect mechanism. The firearm includes a trigger operable between a resting position and a pulled position. The magazine disconnect mechanism has a trigger block positioned between the trigger and a magazine well of the firearm, where the trigger block is movable between a blocking position and a non-blocking position. In the blocking position the trigger block obstructs moving the trigger to the pulled position. The trigger block occupies the non-blocking position when a magazine is installed in the magazine well, and the trigger block occupies the blocking position when the magazine is absent from the magazine well.

US12590774 - Trigger restriction device for conducted energy devices

A trigger restriction device for use with a conducted energy device (CED), contains a blocking member, an attachment member integrally connected to a top of the blocking member and oriented non-parallel to the blocking member, and an adhesion section on an outer surface of the attachment member, configured to adhere the attachment member to an inside of a trigger well when the attachment member is placed against a wall of the trigger well. When the trigger restriction device is attached to a CED, the blocking member is operably configured to block access to the trigger well on one side of the CED while allowing access to the trigger well on an opposing side of the CED.

US12590775 - Trigger lock

A trigger lock provides a high retention force and a low reset force to secure, release and reset a translating member to a stationary member. A retention latch has a complementary shape to engage and resist axial translation of the translating member. The retention latch pivots downward to disengage from the translating member. A spring pack compresses to resist the downward pivot to set the high retention force. A trigger lock assembly restrains the compressed spring pack to allow the translating member to return and reset the trigger lock with the low reset force. A spring-loaded latch clearance cam is configured to push the translating member away from the retention latch as the translating member disengages and returns to reset the trigger lock.

US12590776 - Discreet blank firing adapter

Provided is a blank firing adapter for a firearm that prevents a bullet or fragmentation from exiting a firearm barrel and traveling downrange. The device includes a body, a fore end, an aft end, a bore, a transverse exhaust hole, and a flange. The body is positioned within a muzzle end of the firearm barrel. The fore end includes a solid material to prevent bullet fragmentation from directly exiting the barrel in a direction coinciding with a point-of-aim direction when a live round is fired, and the transverse exhaust hole redirects gas traveling through the bore to a direction transverse to the muzzle end of the barrel. The device generates backpressure to permit automatic cycling of a weapon system, safely catches a fired bullet without any fragmentation to travel downrange, and is visually inconspicuous to the casual observer when installed, while allowing for the use of externally attached devices.

US12590777 - Lever system for lever bow

An archery bow is disclosed. Bows of the present disclosure comprise lever cams. The lever cam includes a base and an elongated lever arm that extends upwards or downwards, depending on which end of the bow the lever cam is attached to. The lever cams are rotatably secured between the split limbs of the bow. In some embodiments, the bows include an adjustment screw to change the position of an offset axle relative to a lever axle. In other embodiments, the bows include a pair of adjustable bowstring modules attachable to the respective elongated lever arms to alter the draw length of the bowstring.

US12590778 - String-unloading apparatus of a crossbow

A crossbow includes a string, a trigger assembly, a safety and a string-unlocking apparatus. Only one hand is required to use a cocking device to operate the string-unlocking apparatus to move the safety to an unlocking position from a locking position and to pivot the trigger assembly to a discharging position from a hooking position.

US12590779 - Stead-field coilgun methods and devices

A method for operating an electromagnetic coilgun system, the method comprising: an electromagnetic coilgun comprising: a barrel and a longitudinally extended electrical excitation coil; wherein the electrical excitation coil circumferentially surrounds a bore of the barrel, energizing the electrical excitation coil to produce a steady-state magnetic field within and around the bore of the barrel, the steady-state magnetic field extending along a longitudinal axis of the barrel; loading the barrel with a magnetic dipole projectile at a breech end of the barrel, wherein the loaded magnetic dipole projectile is oriented with a first magnetic dipole moment aligned to a magnetic field orientation of the steady state magnetic field; and firing the magnetic dipole projectile by magnetically propelling the magnetic dipole along the longitudinal axis of the bore by a magnetic force produced by the steady-state magnetic field within and around the bore of the barrel.

US12590780 - Air gun with onboard electric pump

The present disclosure provides an onboard electric pump assembly for an air gun. The onboard electric pump assembly includes: a high-speed DC motor powered by a battery; a controller that is operable by a user through a user interface, where the controller is configured to control the high-speed DC motor, and a mounting structure to mount the high-speed DC motor within the air gun an air gun.

US12590781 - Preloaded disposable cylinder system for revolver

A preloaded disposable cylinder system for revolvers comprising a disposable cylindrical body, which is preferably 3D printed with chambers preloaded with propellant, primer, and projectile components without cartridge cases. The system includes boss pads and tapered cylinder end guideways for precise alignment, a spring-loaded center pin mechanism for secure retention, and eliminates traditional crane mechanisms and extractors. The design provides faster reload times than conventional revolvers, stronger dual-end cylinder lock-up, enhanced accuracy through improved alignment, and reduced manufacturing complexity. Compatible with existing revolver designs through minor frame modifications.

US12590782 - Archery bow sight support systems

The disclosed technology includes a support system for an optical sighting device of a bow. The support system includes a support structure configured to attach to a bow and an elevation assembly configured to move along an elevation direction relative to the support structure. The support structure can include an elevation actuator configured to cause the elevation assembly to move along the elevation direction when the elevation actuator is actuated and a windage assembly configured to move along a windage direction relative to the support structure. The windage direction can be approximately perpendicular to the elevation direction. The support structure can further include a windage actuator configured to cause the windage assembly to move along the windage direction when the windage actuator is actuated. The windage actuator can be disposed at least partially in the elevation actuator.

US12590783 - Forward-fighting position ballistic shield device

A forward-fighting ballistic shield device is provided. The device is comprised of a ballistic shield device that can function as both a ground-deployed and a carried shield to protect against ballistic blast and fragmentation impacts. The device comprises an aluminum frame attached to a ballistic panel with a polyurethane coating, along with an adjustable telescopic leg secured by a locking mechanism for stability when deployed. A tether further ensures the leg maintains the desired angle, while a fastener secures it parallel to the frame when carried. Additionally, deployable straps with grommets enable staking the device to the ground for enhanced stability. The device further features a rapidly inflatable ballistic panel with an inflatable bladder, capable of being manually or gas-inflated via a canister. The bladder may be reinforced with tensile members or foam-core and absorbs and distributes impact forces.

US12590784 - Handle assembly

A handle assembly is described. Embodiments of the handle assembly can include a main body and a cap. The main body can be contoured to be gripped by a user and can include a chamber for receiving a canister of deterrent spray therein. The contour of the main body can generally index knuckles of a user holding the main body with a dispensing nozzle of a canister configured to dispense a deterrent. The cap can be removably coupled to the main body and can encapsulate the canister in the chamber. To dispense contents of the canister, a user may first pop the cap off to engage the canister, second the user can activate the canister, and third the user can dispense the contents of the canister.

US12590785 - Target pins and target pin holster system

A target pin holster system includes target pins, which are used to secure a paper target face to a penetrable archery target, and a holster that securely stores the target pins when they are not in use. Each target pin houses an embedded magnet which is attracted to a magnet embedded in the target pin retention holster resulting in safe and secure storage for the target pins when they are not in use.

US12590786 - Toy foam dart with impact absorbing tip

A toy form dart having an elongate dart body and a dart tip connected thereto. The dart tip has an outer surface extending from a top to a bottom thereof, and a hollow passage extends through the dart tip in a first direction defining first and second mouth openings on opposing. First and second pairs of eye socket indents are located between the respective first and second mouth openings and the top of the dart tip, with the first and second eye socket indents penetrating partially into the dart tip and an interior boundary wall formed between each one of the first pair of eye socket indents and each respective oppositely located one of the second pair of eye socket indents. The first and second pairs of eye socket indents and the respective first and second mouth openings form a face configuration on the opposing sides of the dart tip.

US12590787 - Modular system for ammunition processing, storage, and transportation

A modular ammunition storage system comprising an insert block and a plurality of cartridge pockets formed into the insert block, such that a distal end of each cartridge pocket may be closed above the bottom surface of the insert block and a proximal end of each cartridge pocket is open at the top surface of the insert block, wherein each cartridge pocket is configured to receive and removably secure a cartridge having a particular shape and caliber. The insert block is receivable and removably securable by an ammunition box insert that surrounds the perimeter of the insert block, the ammunition box insert itself surrounding the interior perimeter of the carrying case into which the insert block and ammunition box insert are received. Different insert blocks configured to hold different caliber ammunition may be provided, and interchanged with one another in the carrying case.

US12590788 - Device method operating electronic detonator having response relay function

A device and a method thereof for operating an electronic detonator having a response relay function are proposed. The device includes a command signal reception unit configured to receive a command signal transmitted from a blasting control system, a response signal transmission unit configured to transmit a response signal responsive to the received command signal to the blasting control system, and a response signal delivery unit configured to transmit the corresponding response signal to the blasting control system when a response signal of another electronic detonator adjacent within a preset distance is recognized.

US12591127 - Optical data insertion

A viewer for an optical data insertion device and a combined system comprising a viewer and an optical data insertion device. The optical data insertion device comprising a projector operable to project a visible image and a light guiding device operable to direct light from the projector into the viewer. The viewer comprising an objective lens, an eyepiece lens and a diffuser screen provided between the objective lens and the eyepiece lens.

US12591786 - Intelligent ammunition co-evolution task assignment method

An intelligent ammunition co-evolution task assignment method is disclosed. The method includes the following steps. A chromosome gene encoding of genetic algorithm for ammunition assignment scheme of multi-platform interception operation is performed. A fitness of chromosome individual function in a genetic population is calculated according to a threat degree of an intercepting target in the ammunition assignment scheme and an interception probability of the intercepting target by different ammunition launching platforms. A probability ranking sequence of effective interception of the intercepting target by different ammunition launching platforms is obtained, and a genetic algorithm selection operation is performed on the chromosome individuals according to probability values of effective interception in descending order of priority. Crossover and/or mutation are performed on the selected chromosome individuals to obtain a next generation genetic population and the above steps are repeated until termination conditions are met to obtain the final ammunition assignment scheme.

USD1121063 - Water gun

US12583309 - Hybrid power system for a military vehicle

A military vehicle includes an engine, an energy storage system comprising a battery, and a motor/generator electrically coupled to the energy storage system and configured to draw power from the energy storage system to drive a tractive element of the military vehicle. The engine is configured to drive the tractive element cooperatively with the motor/generator, but is not configured to drive the tractive element without the motor/generator.

US12583557 - Fuel delivery system

Systems are provided for an engine fuel delivery system for vehicles under test. In one example, a fuel delivery system includes a bulk fuel storage tank to house bulk fuel at low pressure and an on-board fuel tank to house smaller quantities of pressurized fuel to be fed to a vehicle propulsion system. The fuel delivery system further includes a positive displacement pump to pressurize fuel from the bulk fuel storage tank and feed fuel to the on-board fuel tank. A plurality of valves and sensors are further included with an arrangement of fuel lines to monitor and direct fuel flowing in the fuel delivery system.

US12584384 - Perforating gun tube and perforating gun

The present invention relates to a perforating gun tube, characterized in that the tube is made of a steel alloy comprising, in addition to iron, the following alloying elements, expressed in mass percent: C 0.12-0.22% Si 0.3-1.0% Mn 1.0-4% Cr 0.5-2% Mo 0.1-1%, V 0.05-0.2% Ti 0.02-0.1% and B 0.001-0.01% and impurities due to melting, and that the tube has a yield strength, R P0,2 , in the range of 750 to 1100 MPa. In addition, a perforating gun having such a perforating gun tube is described.

US12584386 - Perforating gun with detonation module

An apparatus for selectively firing a perforating gun having a plurality of gun assemblies may include an end plate, a portion of a signal communication circuit, an initiator assembly, and an initiating element. The end plate has a cavity formed by at least a first passage intersecting a second passage. The first passage extends from a planar end face of the end plate and the second passage extends from a circumferential surface of the end plate. The portion of a signal communication circuit is disposed in the end plate and conveys signals between the first gun and the second gun. The initiator assembly is at least partially disposed in the first passage. The initiating element is sized to pass through the second passage. The initiating element is also configured to electrically couple to the portion of the signal communication circuit and to thermally couple to the initiator assembly when at least partially seated in the first passage.

US12584611 - Collapsible supplemental illumination device for sighting device and control method thereof

A collapsible supplemental illumination device for a sighting device, including an illumination unit, a damping motion unit, a locking mechanism, and a position detection device. The damping motion unit is fixedly mounted on a main body of the sighting device. The damping motion unit is connected to the locking mechanism. The position detection device is provided on the locking mechanism. The illumination unit is rotatably connected to the damping motion unit through the locking mechanism. A control method of the collapsible supplemental illumination device is further provided.

US12584618 - Flashlight grip

Disclosed embodiments may include devices and methods for a flashlight grip. The flashlight grip may include a handle with a mount configured to hold a flashlight. The mount may include a first mounting portion coupled to the handle and a second mounting portion coupled to the handle. The second mounting portion may be positioned opposite the first mounting portion. The first mounting portion and the second mounting portion may form a cavity. The flashlight grip may further include one or more connectors extending through the first mounting portion and the second mounting portion that may be used to tighten the first mounting portion and second mounting portion, thereby securing a flashlight in between the first mounting portion and the second mounting portion.

US12584701 - Roller and bearing delayed firearm operating systems

A firearm operating system includes a forward bolt with an internal cavity, a carrier disposed on a rear side of the forward bolt where the carrier includes a cavity, a short cam pin, a plurality of bearings, a retracted configuration, and a deployed configuration. At least a portion of a forward section of the short cam pin is disposed within the internal cavity of the forward bolt. At least a portion of a rear section of the short cam pin is disposed within the cavity of the carrier. Movement from the retracted configuration to the deployed configuration includes movement in a forward/aft direction of the short cam pin relative to the forward bolt and movement of the plurality of bearings.

US12584702 - Grip module for handgun

A grip module system for a handgun or other firearm may include a lower receiver, a pistol grip affixed to the lower receiver, a buffer tube attachment point affixed to a rear portion of the lower receiver, and an accessory rail removably attached to a top of the buffer tube attachment point. The grip module system may be configured to accept and engage the firing components of various semi-automatic and automatic pistols or rifles.

US12584703 - Cam race for improved upper receiver longevity

An apparatus and methods are provided for a cam race for improving the longevity of an upper receiver of a direct gas operated firearm. The cam race provides a hardened slide face and a corner surface for a cam pin comprising a bolt carrier group of the firearm. The cam race is configured to be secured into a window disposed in the upper receiver. The window is surrounded by a counterbored area that receives a back plate of the cam race. The counterbored area and the thickness of the back plate cooperate such that the corner surface and the slide face are positioned to receive the cam pin during reciprocal movement of a bolt carrier group within the upper receiver. The cam race is retained in the upper receiver by fasteners that are tightened into threaded holes in the counterbored area.

US12584704 - Ammunition feed belt linkage bracket

A guidance tab is provided for separating a cartridge round at its base from an aft linkage bracket within an ammunition chain. The tab includes a plate, a pair of legs and a pair of feet, and is composed of polyamide-imide. The plate has an obverse surface for engaging the base of the cartridge round and a reverse surface for engaging the aft linkage bracket. The plate is oriented along a longitudinal direction of the ammunition train and a lateral direction orthogonal to an axial direction of the cartridge round. The pair of legs extends from flanking sides of the plate in the axial direction towards the aft linkage bracket. The pair of feet extend substantially parallel to the plate. Each foot extends from a respective leg of the pair of legs.

US12584705 - Electromechanical gun

The present disclosure provides systems, devices, and techniques that can be implemented at a gun, such as an electromechanical gun. The gun may include a barrel located within a slide and a cylindrical spring enveloping the barrel. The barrel may be configured to act as a guide rod for the cylindrical spring, and the cylindrical spring may be configured to bias the slide in a forward battery position. The gun may include an electronic component such as an energy store, a processor, or a circuit board, located under the barrel and forward of the trigger when the gun is in an upright position. The gun may include a physical transmission medium that electronically couples the electronic component with an additional electronic component located rearward of the trigger, and the physical transmission medium may be at least partially encapsulated by a trigger guard.

US12584706 - Front removeable trigger shoe

A trigger assembly for a 1911 format pistol comprising of a trigger bow having a forward portion defining a first threaded portion, a threaded fastener having a second threaded portion mateable with the first threaded portion, and a trigger shoe configured to operably engage the threaded fastener to secure the trigger shoe to the trigger bow.

US12584707 - Firearm suppressor cover

A firearm suppressor cover ( 1 ), comprising a thermal insulator ( 3 ) which is, in use, configured to surround a firearm suppressor ( 4 ); and a curved spring ( 2 ) which is located at a first end of the cover and pre-bent into a shape of a ring, which is open at one point, the spring ( 2 ) being, in use, configured to tighten around the firearm suppressor ( 4 ) in order to tighten said thermal insulator ( 3 ) around the firearm suppressor ( 4 ) and to prevent the longitudinal movement of said thermal insulator ( 3 ) in relation to said suppressor ( 4 ).

US12584708 - Gun targeting system

A gun targeting system ( 10 ) comprising a chassis ( 200 ). A gun barrel ( 300 ) is mounted to the chassis ( 200 ) by a pivot mount ( 304 ). The system also comprises a chassis suspension system ( 400 ) comprising a plurality of wheel arms ( 402 ), each wheel arm ( 402 ) extending away from a different chassis mount ( 220 ) on the chassis ( 200 ) to a respective wheel ( 404 ), each wheel ( 404 ) being rotatably mounted on its respective wheel arm ( 402 ), each wheel ( 404 ) configured for engagement with a support surface ( 500 ). The gun targeting system ( 10 ) is operable to position the barrel ( 300 ) towards an orientation to target an object by pivoting one or more wheel arms ( 402 ) relative to the chassis ( 200 ) and/or by pivoting one or more wheels ( 404 ) relative to its respective wheel arm ( 402 ) and/or by rotating one or more wheels ( 404 ) relative to its respective wheel arm ( 402 ).

US12584709 - Archery bow riser with stabilizing damper

In some embodiments, an archery bow comprises a riser comprising a grip location and a cavity. A first limb is supported by the riser and attached by a first limb fastener. A second limb is supported by the riser and attached by a second limb fastener. A bowstring extends between the limbs. A vibration damper is located in the cavity, the vibration damper comprising a resilient member and a weight. A first distance from the bowstring to the first limb fastener is less than a second distance from the bowstring to the vibration damper.
