US12292253 - Adapter for airsoft gun
The patent describes an adapter for airsoft guns that integrates a pressurized air reservoir, air inlet and outlet, and a piston valve within a single plastic housing. This design allows for the controlled release of air to propel projectiles, enhancing the functionality of the airsoft gun.
Claim 1
- An adapter for an airsoft gun, comprising: a) a housing comprising a single, integrally formed plastic element, the housing having an upper portion configured to mate with a magazine well of the airsoft gun; b) an air reservoir located within the housing, the air reservoir for holding pressurized gas; c) an air inlet located at a bottom of the housing, the air inlet coupled with the air reservoir and configured for allowing ingress of pressurized air from an attached gas canister; d) an air outlet located at a top of the housing, the air outlet coupled with the air reservoir and configured for allowing egress of pressurized air from the air reservoir to the airsoft gun; e) a piston valve located within the housing between the air reservoir and the air outlet, the piston valve configured for preventing airflow from the air reservoir to the air outlet when in the rest position, and allowing temporary airflow from the air reservoir to the air outlet when contacted by a firing pin of the airsoft gun; f) a projectile inlet located at the bottom of the housing, the projectile inlet configured for allowing ingress of projectiles from an attached projectile magazine; and g) a projectile outlet located at the top of the housing, the projectile outlet coupled with the projectile inlet and configured for allowing egress of projectiles to the airsoft gun. a) a housing comprising a single, integrally formed plastic element, the housing having an upper portion configured to mate with a magazine well of the airsoft gun; b) an air reservoir located within the housing, the air reservoir for holding pressurized gas; c) an air inlet located at a bottom of the housing, the air inlet coupled with the air reservoir and configured for allowing ingress of pressurized air from an attached gas canister; d) an air outlet located at a top of the housing, the air outlet coupled with the air reservoir and configured for allowing egress of pressurized air from the air reservoir to the airsoft gun; e) a piston valve located within the housing between the air reservoir and the air outlet, the piston valve configured for preventing airflow from the air reservoir to the air outlet when in the rest position, and allowing temporary airflow from the air reservoir to the air outlet when contacted by a firing pin of the airsoft gun; f) a projectile inlet located at the bottom of the housing, the projectile inlet configured for allowing ingress of projectiles from an attached projectile magazine; and g) a projectile outlet located at the top of the housing, the projectile outlet coupled with the projectile inlet and configured for allowing egress of projectiles to the airsoft gun.
