Feb 10, 2026
A muzzle device for a firearm may include a device body and a plurality of ball bearings. The device body may be configured to be removably secured to a mount body of a mount configured to be secured to a barrel of the firearm, the mount body including a plurality of lugs each extending radially outward relative to a longitudinal axis of the mount and including a stop and a detent. The device body may include a plurality of protrusions each extending radially inward relative to a longitudinal axis of the muzzle device and configured to engage the stop of a respective lug of the mount to prevent rotation of the muzzle device relative to the mount in a first direction. The ball bearings each may be configured to move relative to the device body and to engage the detent of a respective lug of the mount to inhibit rotation of the muzzle device relative to the mount in a second direction opposite the first direction.
Feb 10, 2026
A visibility-impairing security device is disclosed for producing a gathering of air-suspended light-obscuring matter to obscure vision. The device comprises a body comprising an emission unit receiving portion for holding an emission unit having an outlet for emitting the matter; an opening for the passing therethrough of the matter from the outlet; and a door for closing the opening. The door is configured to move between a closed position in which the opening is covered and an open position in which the opening is at least partially open, thus allowing for the passing therethrough of the matter from the outlet when the door is in the open position.
Jan 27, 2026
The present disclosure relates to the illuminant structure technical field. Disclosed are a light source structure, a sighting device and a shooting device, wherein the sight light source structure is used for the sighting device. The light source structure includes a substrate, a light-emitting chip arranged on the substrate, a bonding wire configured for electrically connecting the substrate and the light-emitting chip, and light-absorbing glue coated on the bonding wire. By improving the structure of the light source structure, specifically, by not covering the light-transmitting protective layer on the light-emitting chip, the light-transmitting protective layer is effectively prevented from reflecting light, so that the aiming point formed by the light at the light-emitting place is gathered, and the edge of the aiming point has no stray reflected light so that the wheel library at the edge of the aiming point is clear.
Jan 20, 2026
A storage device comprising a mounting bracket, a sliding assembly, and at least one mount by which to provide an interface for hanging and storing handguns within a cabinet or other suitable storage space whereby the sliding assembly can project outward from the storage device for unencumbered access to the handguns.
Jan 13, 2026
A noise suppression device for a firearm includes a body including an internal surface; a plurality of raised strips protruding from the internal surface; and a plurality of fins corresponding to and extending from the plurality of raised strips, respectively, wherein the noise suppression device includes no joints, no seams, or any formerly separate pieces within the body or a core.
Oct 21, 2025
Firearm recoil attenuating devices may include a firearm support base having a base interior; a filler material in the base interior of the firearm support base, the filler material having a recoil-absorbing portion; and a recoil attenuating strap carried by the firearm support base proximate the recoil-absorbing portion of the filler material, the recoil attenuating strap configured for attachment to the firearm to transmit the recoil force from the firearm to the recoil-absorbing portion of the filler material upon firing of the firearm.
Oct 7, 2025
A firearm trigger control device, which is adapted to control the displacement of a firearm's trigger, such as to enable the discharge of a projectile upon receiving a firing signal (e.g., at a timing determined as optimal for hitting a designated target).
Oct 7, 2025
A method and apparatus for counting belted or bulk ammunition rounds. The modular ammunition counter includes a detachable electronics assembly, an ammunition guide for receiving the ammunition rounds, and a sensor module. The electronics assembly is configured to count the number of ammunition rounds that pass through the coupled ammunition guide. This method of ammunition round counting offers a significant improvement in speed and accuracy compared to manually counting the ammunition rounds by hand.
Sep 30, 2025
A constant intensity light regulating firearm sight device includes a main body that is mountable onto the firearm and a lens that is positioned along the main body in a direction that is line of sight parallel to a firing axis of the firearm. The device includes a light source, a light sensor and a controller that are positioned along the main body. The light source emits a visible aim point onto the lens, and the light sensor detects and reports ambient light conditions to the controller. The controller includes a memory and processor for storing information and for controlling the operation of the device based on inputs from a user interface and the light sensor. The brightness level of the aim point is adjustable to a user-defined custom brightness setting, and the controller increases or decreases the custom brightness level based on data from the light sensor.
Sep 23, 2025
A retention device for a firearm includes a latching lever mountable to a trigger guard of the firearm, and a latching receiver configured to receive and retain the firearm. The latching lever is pivotable about a first pivot point between a first engaging position and a second release position. The latching receiver is configured to receive and retain the firearm, and includes a latch pivotable about a second pivot point between a firearm engaging position and a firearm release position. The latch has a protrusion configured to engage and retain the firearm when the latching lever is in the first engaging position.
Aug 26, 2025
A smart aiming device includes an image sensor, a processor, and an adjustable reticle. A method of zeroing the smart aiming device includes: activating a dedicated zeroing mode: shooting at least one bullet on a zeroing target while aiming the firearm on the target using the reticle to determine an expected point of impact of the bullet on the zeroing target: imaging the zeroing target with the image sensor: identifying a location of at least one bullet hole formed by the bullet on the target, and calculating a distance between each bullet hole and the expected point of impact; and adjusting a location of the reticle respective to the bore of the firearm based on the calculated at least one distance, to thereby indicate a zeroed point of impact on the target on which a subsequent bullet shot from the firearm is expected to impact.
Aug 26, 2025
An ammunition cartridge case reloading die has a die body defined by an interior bore and a bore opening, and a retention cap attachable to the die body. A cartridge case tool is fixed to the retention cap in axial alignment with the interior bore, and a tip of the cartridge case tool is at a proscribed distance relative to the bore opening. A centering shuttle is in sliding engagement in the interior bore of the die body, and defines a shuttle bore through which the cartridge case tool passes, and a reverse taper opening receptive to the cartridge case. The die may has a biasing element disposed within the interior bore between the centering shuttle and the retention cap, with movement of the centering shuttle within interior bore of the die body being dampened by the biasing element.
Aug 19, 2025
The technology relates to a long-range optical device for a firearm with an objective and an eyepiece, through which an observation beam path is formed for aiming at a target, the long-range optical device further comprising an opto-electronic display device, wherein the display device comprises an LCoS display for displaying variable data or a target mark, wherein a display beam path of the display device runs at least partly in the observation beam path for displaying the remote object.
May 27, 2025
A firearm mounting device securable to a surface and having a magnetic material within a base to attract and secure a firearm to the device in a readily retrievable position. The device includes a channel to receive the slide of a semi-automatic pistol and at least one slide stop disposed within the channel to engage and prevent movement of the slide as a user grips the grip of the pistol and displaces the grip towards the at least one slide stop to chamber a cartridge in the chamber of the pistol. The at least one slide stop engages and prevents movement of the slide while allowing the barrel of the pistol to protrude from under the slide.
May 13, 2025
A firearm safety device includes a clip including a bend between a first end and a second end, wherein the clip is configured to mate with a firearm that comprises an accessible safety selector rod, and thereby place the firearm in a safety-locked position, wherein a section of the clip that extends to the first end is configured to be inserted into a gap of the firearm behind the safety selector rod and thereby prevent rotation of the safety selector rod in the safety-locked position., and wherein a section of the clip that extends to the second end is configured to be retained against an opposing surface of the firearm in the safety-locked position.
Apr 15, 2025
A device for holding and loading shotgun shells is provided. The device includes a resilient pad having a front side with a pair of openings for receiving, retaining, and releasing a pair of shells into the barrel of a shotgun. The openings include a plurality of expansion joints to assist with the loading and unloading of shells into a gun. An annular groove extends around a base of each opening for resiliently and frictionally retaining the rim of a shell therein. An opposing end of the pad includes a laterally projecting tab portion formed with an aperture therethrough for a user of the holding device to manually grasp and manipulate said device. The expansion joints and material of the pad facilitate the insertion and release of the shells, whereas the groove and size of the openings serve to frictionally retain the shells within the device.
Apr 15, 2025
An apparatus, for use with a projectile launching device, includes the sight, including a viewfinder that permits a user to view an image of a target in association with a reticle, a digital image system for capturing images of the target, multiple sensors to detect a firing time the apparatus for capturing multiple first images at or close to said firing time, wherein an image processor compares images captured after said firing time with said multiple first images, and to identify an indication of a projectile impact on said target, the apparatus being configured to capture multiple second images after said firing time and including said projectile impact indication, and wherein the apparatus includes a reticle adjuster to automatically position the reticle in the viewfinder in accordance with comparison between first images and second images and the associated positions of the reticle and the projectile impact indication.
