Feb 3, 2026
A bolt head of a breech block includes a base element, a breech face arranged on the front of the base element, and a bezel enclosing the breech face in an annular fashion. The bezel is formed by several bezel parts detachably fastened to the base element.
Jan 27, 2026
A bolt stop actuator is disclosed. The actuator may include a lift arm, a first leg extending from a point proximate to an end of the lift bar and generally perpendicular therefrom, a second leg extending in the same direction from the lift bar as the first leg, and a projection extending from the lift bar and configured to contact a follower of an empty magazine when the bolt stop actuator is assembled into a firearm. Neither the first leg, nor the second leg, include apertures positioned distal to the lift arm.
Jan 13, 2026
A multi-caliber firearm includes a barrel extension configured to connect to an interchangeable barrel that is selected from at least two predetermined caliber sizes. An interchangeable magazine well receives a magazine that is selected to house cartridges from the predetermined caliber sizes. The magazine well includes a first end facing towards the stock and a second end facing towards the barrel extension. A bolt carrier group includes a bolt carrier and a bolt. A reverse movement unloads a used cartridge from the bolt and a forward movement loads a new cartridge from the magazine. The bolt carrier group receives an interchangeable bolt that is selected to load and unload one of the predetermined caliber sizes. The bolt includes a longitudinal cartridge retaining notch facing towards the magazine. The cartridge retaining notch is configured to retain the new cartridge in the magazine during the reverse movement.
Nov 11, 2025
An ambidextrous bolt catch system for a firearm receiver includes a neck having upper, middle, and lower portions; a bolt catch at the upper portion; and an ambidextrous actuator at the lower portion having a spring retention structure. The middle portion extends along a plane perpendicular to a vector extending from the rear to the front of the receiver, and includes a first terminal point towards one side of the receiver, the upper portion extends along the plane and includes a second terminal point towards the side and further than the first terminal point, and the lower portion extends along the plane and includes a third terminal point towards the side and beyond the first terminal point.
Sep 30, 2025
A firearm having a forward charging handle that allows a shooter to cycle the bolt without significant change in posture or stance. This allows the shooter to overcome ammunition related difficulties without needing to reach to a rear charging handle to cycle the firearm. The forward charging handle may be located near the shooter's support hand on the foregrip/handguard, which reduces the amount of time and positioning needed to cycle the bolt.
Aug 19, 2025
A firearm comprises a frame having a barrel and defining a passage registered with the barrel, with a bolt configured to reciprocate in the passage between a forward battery condition and a retracted condition. A latch that is movable between a retention position in which the bolt is prevented by the latch from moving from the retracted position to the battery position, and a release condition in which the bolt is prevented by the latch from moving from the retracted position to the battery position. The latch is biased to the retention position such that the bolt is retained in the retracted position after every shot; and an actuator connected to the latch and configured to move the latch to the release condition.
Aug 5, 2025
A manual bolt assembly for a firearm may include a bolt carrier, a bolt, a cam lock, and a bolt handle. The bolt carrier may include a first central passage extending from a proximal end to a distal end of the bolt carrier, and a cutout defined along a side of the bolt carrier. The bolt may extend through the first central passage and may include a second central passage extending from a proximal end of the bolt, and a first aperture extending through a wall of the bolt to the second central passage. The cam lock may engage the bolt carrier and may include an arm movably disposed within the cutout, a third central passage extending from a proximal end of the cam lock, and a second aperture extending through a wall of the cam lock to the third central passage. The bolt handle may be coupled to the cam lock and may include a lever extending away from the cam lock, and a protrusion extending through the second aperture and through the first aperture.
Jul 8, 2025
A compact action for a firearm including an upper receiver housing incorporating a barrel. A bolt and carrier are positioned within the receiver housing so that the bolt is engaged to a rear receiver end of the barrel in a cartridge chambering position. Guide rods are supported within the housing above the barrel and extend in parallel to a rear located end plate. The carrier includes a carrier key supported by and displaceable along the guide rods between the barrel and a rearward bumper component. A gas tube extends from a forward located gas block overlaying a gas discharge aperture in the barrel to a gas key for actuating the carrier rearwardly following discharge of a ballistic from the barrel. A fixed ejector is attached to the upper receiver, in combination with machining a slot into the carrier and the bolt, such that the ejector remains static such that, upon the bolt cycling, the spent shell casing contacts the ejector, causing it to be ejected out of the upper receiver.
Jul 8, 2025
A firearm is disclosed. The firearm can include an upper receiver that includes a bolt. The bolt can include at least one displaceable biasing member that is configured to bias the bolt in a forward state when the at least one biasing member is in an initial state. The bolt can also include a locking wedge that is configured to bias the at least one displaceable biasing member in the initial state. The at least one displaceable biasing member is configured to be displaced from the initial state to a displaced state when a sufficient amount of force is exerted on the at least one displaceable biasing member from the bolt so that the bolt can transition from the forward state to a backward state.
Jul 8, 2025
Jun 3, 2025
A modular two-piece bolt system for firearms with blowback actions provides a rear bolt piece which detachably couples to plural different front bolt pieces each of different mass. The front bolt pieces have a similar configuration and common coupling interface which forms an interlocked relationship with a complementary configured coupling interface on the rear bolt piece to prevent axial separation of the pieces when the action of the firearm is cycled. The system allows various front bolt pieces to be selected and used interchangeably with the rear bolt piece so that a front bolt piece of proper mass can be matched to the energy of ammunition to be fired. The front and rear bolt pieces when coupled define a continuous extended longitudinal passage which receives the rear breech end portion of the firearm barrel therethrough to reduce the projected length of the barrel.
May 20, 2025
An operating system for a firearm includes a trigger, a hammer, a disconnector, a pivoting arm, and a lower member. The trigger includes a lower portion, an upper portion, and a trigger pivot. The disconnector includes a lower portion, an upper portion, and a disconnector pivot. The pivoting arm includes a forward protrusion, a pivoting arm opening, and a pin extending through the pivoting arm opening. The lower member includes a lower member opening and a pin hole that is coaxial with the trigger pivot and the disconnector pivot. At least a portion of the trigger and at least a portion of the disconnector are disposed within the lower member opening. Motion of the trigger causes the forward protrusion of the pivoting arm to engage a bolt carrier group and hold the bolt carrier group in an open position.
