US12693085 - Accessory for a firearm, and firearm

The patent describes an accessory for firearms that utilizes a permanent magnet to capture ejected casings, enhancing user convenience and cleanliness. The accessory is designed to be adjustable in multiple positions relative to the firearm’s barrel, allowing for customization based on the firearm’s geometry.

Claim 1

1 . Accessory for a firearm of predetermined geometry including a casing ejection window defining a path of a casing ejected from this firearm upon firing, which accessory comprises: a permanent magnet, and a support attached to the firearm, configured to position a surface of the permanent magnet in the path of the casing or tangentially to the path of the casing, which support comprises a mounting plate attached to the firearm and a removable mounting support bearing the magnet, the mounting support being configured to be secured to the mounting plate in several respective positions along an axis parallel to the axis of the barrel of the firearm, the mounting support being configured to be secured to the mounting plate in several respective positions in a plane perpendicular to the axis of the barrel of the firearm. a permanent magnet, and a support attached to the firearm, configured to position a surface of the permanent magnet in the path of the casing or tangentially to the path of the casing, which support comprises a mounting plate attached to the firearm and a removable mounting support bearing the magnet, the mounting support being configured to be secured to the mounting plate in several respective positions along an axis parallel to the axis of the barrel of the firearm, the mounting support being configured to be secured to the mounting plate in several respective positions in a plane perpendicular to the axis of the barrel of the firearm.
