Jun 23, 2026

US12663243 - Multifunction portable illumination system

A multifunction portable illumination system includes a housing having a power source. A broadband illumination source connected to the power source and capable of producing broadband illuminating light. The system includes an imaging disruption assembly including at least one narrow-band light source capable of generating one or more high intensity light beams (HILB) and a light modifying assembly configured to modify the one or more HILB to produce a Modified HILB. At least one Modified HILB may have the requisite irradiance to cause disruption of an imaging system.

Assignee: IMMOBILEYES INC.
Inventors: Bahman Taheri, Atossa Alavi
Filing date: 2023-06-06

The patent describes a multifunction portable illumination system designed to disrupt imaging systems using high intensity light beams (HILB) generated from narrow-band light sources. The system includes a broadband illumination source and a light modifying assembly that produces pulsed Modified HILBs with specific irradiance levels, without utilizing laser beams.

Claim 1

1 . A multifunction portable illumination system comprising: a housing comprising a power source; a broadband illumination source connected to the power source and capable of producing broadband illuminating light; and an imaging disruption assembly comprising at least two narrow-band light sources capable of generating two or more high intensity light beams (HILB) and a light modifying assembly configured to modify the two or more HILB to produce at least a first and a second Modified HILB; wherein the HILB does not include a laser beam, wherein each Modified HILB has the requisite irradiance to cause disruption of an imaging system, and wherein the first and second Modified HILBs are pulsed in a preprogrammed sequence characterized by a first pulse profile and a second pulse profile, respectively. a housing comprising a power source; a broadband illumination source connected to the power source and capable of producing broadband illuminating light; and an imaging disruption assembly comprising at least two narrow-band light sources capable of generating two or more high intensity light beams (HILB) and a light modifying assembly configured to modify the two or more HILB to produce at least a first and a second Modified HILB; wherein the HILB does not include a laser beam, wherein each Modified HILB has the requisite irradiance to cause disruption of an imaging system, and wherein the first and second Modified HILBs are pulsed in a preprogrammed sequence characterized by a first pulse profile and a second pulse profile, respectively.
