Dec 30, 2025

US12510319 - Recoil shot detection in an extended reality system

An apparatus for detecting a firing of a weapon coupled to an extended reality computing system includes a shot detect sensor coupled to a hammer of a weapon and configured to generate a first signal based at least in part on a position of the hammer. A signal comparator is configured to obtain the first signal and a second signal corresponding to a setpoint and to generate a shot detect signal that corresponds to a firing of the weapon. A timer circuit is configured to generate an extended signal based at least in part on the shot detect signal that has a duration greater than the shot detect signal. A shot detect circuit is configured to indicate to an extended reality tracker device that the weapon has been fired based at least in part on the extended signal.

Assignee: STREET SMARTS VR INC.
Inventors: Gregory Prodzenko
Filing date: 2023-03-21

The patent describes an apparatus for detecting the firing of a weapon that integrates with an extended reality computing system, utilizing a shot detect sensor linked to the weapon’s hammer. This system generates a shot detect signal based on the hammer’s position and a setpoint comparison, which is then used to inform an extended reality tracker that the weapon has been fired.

Claim 1

1 . An apparatus for detecting a firing of a weapon coupled to an extended reality computing system, the apparatus comprising: a shot detect sensor coupled to a hammer of a weapon, the shot detect sensor being configured to generate a first signal based at least in part on a position of the hammer; a signal comparator that is configured to obtain the first signal from the shot detect sensor and a second signal corresponding to a setpoint, the signal comparator being configured to generate a shot detect signal based at least in part on a comparison of the first signal and the second signal, the shot detect signal corresponding to a firing of the weapon; a timer circuit that is configured to generate an extended signal based at least in part on the shot detect signal, the extended signal having a duration greater than the shot detect signal; and a shot detect circuit that is configured to indicate to an extended reality tracker device that the weapon has been fired based at least in part on the extended signal. a shot detect sensor coupled to a hammer of a weapon, the shot detect sensor being configured to generate a first signal based at least in part on a position of the hammer; a signal comparator that is configured to obtain the first signal from the shot detect sensor and a second signal corresponding to a setpoint, the signal comparator being configured to generate a shot detect signal based at least in part on a comparison of the first signal and the second signal, the shot detect signal corresponding to a firing of the weapon; a timer circuit that is configured to generate an extended signal based at least in part on the shot detect signal, the extended signal having a duration greater than the shot detect signal; and a shot detect circuit that is configured to indicate to an extended reality tracker device that the weapon has been fired based at least in part on the extended signal.
