US12460890 - Simulated trigger assemblies

The patent describes a simulated trigger assembly for firearms that utilizes a magnet and a moveable portion to create a two-stage fire control simulation. In its initial configuration, the magnet is adjacent to the moveable portion, which separates in the simulated fired configuration.

Claim 1

1 . A simulated trigger assembly for a firearm comprising: at least one body comprising at least one recess; a magnet disposed within the at least one recess; an initial configuration; and a simulated fired configuration, wherein: in the initial configuration the magnet is at least immediately adjacent to a moveable portion; in the simulated fired configuration the moveable portion has moved to separate the moveable portion from the magnet; the simulated trigger assembly is configured to simulate a two stage fire control group; and the magnet is arranged in a fixed position. at least one body comprising at least one recess; a magnet disposed within the at least one recess; an initial configuration; and a simulated fired configuration, wherein: in the initial configuration the magnet is at least immediately adjacent to a moveable portion; in the simulated fired configuration the moveable portion has moved to separate the moveable portion from the magnet; the simulated trigger assembly is configured to simulate a two stage fire control group; and the magnet is arranged in a fixed position.
