US12449214 - Hybrid ambidextrous receiver

The patent describes a hybrid ambidextrous firearm receiver assembly that features a receiver body with multiple functional components, including a magazine release, bolt release, and safety selector, all designed for use on either side of the firearm. The design includes a threaded mount and a pin that defines a rotational axis for the magazine release assembly, enhancing usability for both left- and right-handed users.

Claim 1

1. A firearm receiver assembly comprising: a receiver body; a threaded mount at a rear portion of the receiver body; a magazine release assembly comprising a magazine release portion on at least one side of the receiver body; a bolt release assembly comprising a bolt release portion on at least one side of the receiver body; a safety selector assembly comprising a safety portion on at least one side of the receiver body, wherein: the magazine release assembly comprises a pin defining a rotational axis; and the pin comprises a fastener with threads. a receiver body; a threaded mount at a rear portion of the receiver body; a magazine release assembly comprising a magazine release portion on at least one side of the receiver body; a bolt release assembly comprising a bolt release portion on at least one side of the receiver body; a safety selector assembly comprising a safety portion on at least one side of the receiver body, wherein: the magazine release assembly comprises a pin defining a rotational axis; and the pin comprises a fastener with threads.

Google Patents

https://patents.google.com/patent/US12449214

USPTO PDF

https://image-ppubs.uspto.gov/dirsearch-public/print/downloadPdf/12449214
