US12422213 - Arrow magazine replacing device
The patent describes an arrow magazine replacing device designed for use with a bow unit, featuring a frame member that allows for the easy attachment and detachment of an arrow magazine unit without the need for additional tools. This innovation aims to enhance the efficiency and convenience of arrow handling during archery activities.
Claim 1
- An arrow magazine replacing device, disposed on an arrow portion of a bow unit, the arrow magazine replacing device comprising: a frame member, mounted on the arrow portion of the bow unit, the frame member includes a mounting part being hollow on one side toward the other side; and an arrow magazine unit, detachably assembled and disassembled in the mounting part. a frame member, mounted on the arrow portion of the bow unit, the frame member includes a mounting part being hollow on one side toward the other side; and an arrow magazine unit, detachably assembled and disassembled in the mounting part.
