Jun 24, 2025

US12339082 - Suppressor attachment system

A disclosed attachment system for a energy suppression device may include an energy suppression device and an attachment mechanism secured to the energy suppression device. The attachment device may include a first lever and a second lever, the first lever may be rotatable with respect to the second lever such that the first lever may apply a force against the second lever when in a locked position and the force may be reduced when the first lever is moved to an unlocked position. The first lever may have a slot having a width that tappers from a first end of the slot to a second end of the slot. The slot may be configured to receive a tool to apply additional force to move the first lever from the locked position to the unlocked position.

Inventors: Russell Oliver
Filing date: 2023-12-22

suppressorfirearmattachment

The patent describes an attachment system for an energy suppression device featuring a dual-lever mechanism that allows for locking and unlocking through rotational movement. The first lever includes a tapered slot designed to accommodate a tool for applying additional force to facilitate the transition between locked and unlocked positions.

Claim 1

An attachment system for a energy suppression device comprising: an energy suppression device; an attachment mechanism secured to the energy suppression device; the attachment mechanism including: a first lever and a second lever, wherein the first lever is rotatable with respect to the second lever such that the first lever applies a force against the second lever when in a locked position and the force is reduced when the first lever is moved to an unlocked position; the first lever having a slot having a width that tappers from a first end of the slot to a second end of the slot; and wherein the slot is configured to receive a tool to apply additional force to move the first lever from the locked position to the unlocked position.
